1350 Series Customized LQ35HR001 Double Cardan CV Head

Home

>

Double Cardan Joint

>

1350 Series Customized LQ35HR001 Double Cardan CV Head

The double cardan cv head is engineered to handle large-angle, non-collinear power transmission with precision. Featuring a dual-joint structure and accurate phase control, it eliminates the speed fluctuation found in single U-joints, ensuring true constant velocity and smooth operation. Built on an advanced constant-velocity technology platform, both high-performance standard models and fully customized solutions are available — tailored in length, mounting design, and dynamic performance. Widely used in steering axles, heavy-duty machinery, and high-precision industrial systems, the double cardan cv head delivers efficient, reliable torque transfer while minimizing vibration and noise.

Fits Vehicles

DOUBLE CARDAN CV HEAD SPECIFICATIONS
U-joints series	1350
Bolt Hole Spacing Height---G	2.76in/70.0mm
Bolt Hole Spacing Width---H	1.63in/41.3mm
Overall Length----A	4.31in/109.50mm
Butt Diameter ----D	2.31in/58.80m
Tubing Diameter	Customized
Tubing Wall	Customized
Hole Diameter /Thread Size----I	4-5/16-24UNF
Center Line To Center Line Of "H" Yoke----C	2.88in/73.03mm
Center Line To Point Of Weld----B	1.44in/36.50mm
Grease Type	Yes
Work angle	22 Degree
Material	45#/C45E/40Cr/42CrMo4

Service

Delivery	20~45 days
Packing	Neutral packing/Liqun packing/Custom packing
Warranty	1 years

Part Interchanges

Neapco No	/
Spicer No	/

Professional Solution for Vibration Issues

The dual-joint constant velocity design effectively eliminates vibration and speed fluctuations caused by large-angle transmission, ensuring smoother and more stable power delivery.

Robust Materials, Superior Craftsmanship

Core components are made from high-quality alloy steel and undergo advanced carburizing heat treatment for excellent wear resistance, impact strength, and long service life.

Flexible Customization, Small Batches Welcome

We support small-batch prototyping and custom development. Whether you’re launching a new project or upgrading existing products, we’re ready to collaborate closely with you.

Better Value for Large Orders

With large-scale production capabilities, we offer highly competitive pricing — the greater the volume, the stronger the cost advantage.

Regular Lubrication

Apply suitable high-performance grease at recommended intervals to reduce friction, minimize wear, and maintain smooth operation under varying load conditions.

Periodic Inspection

Check for abnormal noise, vibration, or excessive backlash during operation. Inspect seals, boots, and fasteners regularly to prevent contamination and premature failure.

Alignment and Load Control

Ensure correct installation alignment and avoid operating beyond the designed angle and torque limits. Proper load management significantly extends service life.

Timely Replacement of Worn Parts

If wear or deformation is detected in key components, replace them promptly to prevent secondary damage and maintain system stability.

Material Selection

We use premium-grade alloy steel sourced from reliable suppliers, selected specifically for high strength, fatigue resistance, and machinability.

Precision Machining

Advanced CNC machining guarantees accurate dimensions, smooth surfaces, and excellent component compatibility, ensuring stable power transmission.

Heat Treatment

Key components undergo carburizing and quenching processes to enhance surface hardness while retaining core toughness, improving wear resistance and impact performance.

Assembly & Quality Inspection

Each unit is assembled by experienced technicians and subjected to dimensional checks, balance inspection, and functional testing before delivery.

Avoid Overloading

Do not exceed the rated torque, speed, or operating angle. Overloading may cause accelerated wear or structural failure.

Correct Installation

Improper installation or misalignment can lead to vibration, noise, and reduced service life. Installation should follow technical specifications and guidelines.

Environmental Considerations

Avoid prolonged exposure to extreme temperatures, corrosive environments, or heavy contamination without proper protection.

Do Not Modify Without Approval

Unauthorized modification or disassembly may compromise performance and safety. For special requirements, consult our engineering team in advance.

1480 Series Customized LQ48WA001 Double Cardan CV Head

286.33 Series Customized LQ286WA001 Double Cardan CV Head

1350 Series Customized LQ35FT70M01 Double Cardan CV Head

Faq

What problems does the double cardan joint solve? How is it different from a single U-joint?

It mainly addresses vibration and speed fluctuation issues.  A single U-joint creates speed variation during rotation, while the double-joint design — with dual pivots and precise phase alignment — achieves near-constant velocity transmission.  The result is smoother, quieter power delivery, ideal for high-performance steering systems and precision drivetrains.

We have a new project with small demand, still in the trial stage. Can you handle that?

Absolutely. We fully support new product development, and small-batch prototyping is one of our strengths.  Whether you need samples for testing or a limited production run, we’ll work closely with you to turn your design into reality.

What materials do you use for key components? How do you ensure durability?

We never compromise on materials.  Critical parts such as the cross shaft and yokes are made from premium alloy steel and undergo advanced carburizing heat treatment — making the surface extremely wear-resistant while keeping the core tough and impact-resistant.  This ensures outstanding durability and a long service life.

What’s the process if we need customization?

It’s straightforward: you provide the requirements (such as size, torque, and angle) → we evaluate and offer a technical proposal and quotation → once confirmed, production begins.  Our engineering team stays in close contact throughout the process to ensure the final product meets your exact specifications.

Do bulk orders offer better pricing and lead time?

Definitely. Large-volume production is one of our biggest advantages.  Thanks to efficient manufacturing and a well-optimized supply chain, we can offer highly competitive pricing along with fast, reliable delivery — saving you both time and cost.

If you have more specific questions, please feel free to contact us — our team will be happy to provide a tailored solution for your needs.

From large-scale production to tailored parts, LIQUN is here to support your needs.
